| Tên thương hiệu: | original |
| Số mẫu: | Ts2 068Z400 |
| MOQ: | 1pcs |
| giá bán: | discussed |
| Thời gian giao hàng: | 7-10 working days after received your payment |
| Điều khoản thanh toán: | L/C, T/T, Western Union |
Specifications:
1. Regriratant:R404A/R507/R22/R134a/R12/R502
2.Thermostatic expansion valve regulate the flow of refrigerant liquid into The evaporator.
3.The flow is controlled by the valve is thermal bulb which is Attached to the suction line at the outlet of the evaporator.
4.The thermal Bulb senses the evaporator heat and adjusts the valve to admit refrigerant Liquid in accordance with the refrigerating load.
| TX Valves | ||||
| Model T2 & TE2 (with Interchangeable Orifice Assembly) | ||||
| Part Number | Refrigerant | Model | Connections | Equaliser Connection |
| Range N: -40° to +10°C – without MOP | ||||
| 068Z3400 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3403 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3206 | R22 | TX2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3209 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3346 | R134a | TN2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3348 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3202 | R12 | TF2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3204 | TEF2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3212 | R502 | TY2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3215 | TEY2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3414 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3415 | TES2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| 068Z3281 | R22 | TX2 | 3/8" Fl. x 1/2" ODF | INT. |
| 068Z3284 | TEX2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| 068Z3383 | R134a | TN2 | 3/8" Fl. x 1/2" ODF | INT. |
| 068Z3385 | TEN2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| Range N: -40° to +10°C – with MOP | ||||
| 068Z3402 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3405 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3208 | R22 | TX2 | 3/8" x 1/2" Fl. | INT |
| 068Z3211 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3347 | R134a | TN2 | 3/8" x 1/2" Fl. | INT |
| 068Z3349 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| Range NM: -40° to -5°C – with MOP | ||||
| 068Z3225 | R22 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL |
| Range NL: -40° to -15°C – with MOP | ||||
| 068Z3408 | R404A/R507 | TS2 3/8" x 1/2" Fl. | INT | |
| 068Z3409 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3226 | R22 | TX2 | 3/8" x 1/2" Fl. | INT |
| 068Z3227 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3369 | R134a | TN2 | 3/8" x 1/2" Fl. | INT |
| 068Z3370 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" | |
| 068Z3430 | R404 | TES2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL |
| Range B: -60° to -25°C – with MOP | ||||
| 068Z3410 | R404A | TS2 | 3/8" x 1/2" Fl. | INT |
| 068Z3411 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3232 | R502 | TY2 | 3/8" x 1/2" Fl. | INT |
| 068Z3233 | TEY | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3420 | R404 | TS2 | 3/8" Fl. x 1/2" ODF INT | |
| Range B: -60° to -25°C – without MOP | ||||
| 068Z3404 | R404A | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL |
|
|
| Tên thương hiệu: | original |
| Số mẫu: | Ts2 068Z400 |
| MOQ: | 1pcs |
| giá bán: | discussed |
| Chi tiết bao bì: | Carton box |
| Điều khoản thanh toán: | L/C, T/T, Western Union |
Specifications:
1. Regriratant:R404A/R507/R22/R134a/R12/R502
2.Thermostatic expansion valve regulate the flow of refrigerant liquid into The evaporator.
3.The flow is controlled by the valve is thermal bulb which is Attached to the suction line at the outlet of the evaporator.
4.The thermal Bulb senses the evaporator heat and adjusts the valve to admit refrigerant Liquid in accordance with the refrigerating load.
| TX Valves | ||||
| Model T2 & TE2 (with Interchangeable Orifice Assembly) | ||||
| Part Number | Refrigerant | Model | Connections | Equaliser Connection |
| Range N: -40° to +10°C – without MOP | ||||
| 068Z3400 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3403 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3206 | R22 | TX2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3209 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3346 | R134a | TN2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3348 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3202 | R12 | TF2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3204 | TEF2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3212 | R502 | TY2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3215 | TEY2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3414 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3415 | TES2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| 068Z3281 | R22 | TX2 | 3/8" Fl. x 1/2" ODF | INT. |
| 068Z3284 | TEX2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| 068Z3383 | R134a | TN2 | 3/8" Fl. x 1/2" ODF | INT. |
| 068Z3385 | TEN2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL | |
| Range N: -40° to +10°C – with MOP | ||||
| 068Z3402 | R404A/R507 | TS2 | 3/8" x 1/2" Fl. | INT. |
| 068Z3405 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3208 | R22 | TX2 | 3/8" x 1/2" Fl. | INT |
| 068Z3211 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3347 | R134a | TN2 | 3/8" x 1/2" Fl. | INT |
| 068Z3349 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| Range NM: -40° to -5°C – with MOP | ||||
| 068Z3225 | R22 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL |
| Range NL: -40° to -15°C – with MOP | ||||
| 068Z3408 | R404A/R507 | TS2 3/8" x 1/2" Fl. | INT | |
| 068Z3409 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3226 | R22 | TX2 | 3/8" x 1/2" Fl. | INT |
| 068Z3227 | TEX2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3369 | R134a | TN2 | 3/8" x 1/2" Fl. | INT |
| 068Z3370 | TEN2 | 3/8" x 1/2" Fl. | EXT 1/4" | |
| 068Z3430 | R404 | TES2 | 3/8" Fl. x 1/2" ODF | EXT 1/4" FL |
| Range B: -60° to -25°C – with MOP | ||||
| 068Z3410 | R404A | TS2 | 3/8" x 1/2" Fl. | INT |
| 068Z3411 | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3232 | R502 | TY2 | 3/8" x 1/2" Fl. | INT |
| 068Z3233 | TEY | 3/8" x 1/2" Fl. | EXT 1/4" FL | |
| 068Z3420 | R404 | TS2 | 3/8" Fl. x 1/2" ODF INT | |
| Range B: -60° to -25°C – without MOP | ||||
| 068Z3404 | R404A | TES2 | 3/8" x 1/2" Fl. | EXT 1/4" FL |
